Install portainer + traefik on Ubuntu 16.04

1. Install docker

https://docs.docker.com/install/linux/docker-ce/ubuntu/

READ ALSO

What is the location of the MySQL databases?

April 24, 2022

504

Top 10 Best WordPress SEO themes of 2022

March 16, 2022

381

2. Install docker-compose

https://docs.docker.com/compose/install/

3. Install traefik

3.1 First, create a directory for our containers:

mkdir -p /opt/containers/{traefik,portainer}

3.2 Create the data folder and config files for Traefik:

mkdir -p /opt/containers/traefik/data
touch /opt/containers/traefik/data/acme.json
chmod 600 /opt/containers/traefik/data/acme.json
touch /opt/containers/traefik/data/traefik.yml

3.3 Create the basic Traefik configuration file:

location: /opt/containers/traefik/data/traefik.yml

api:
  dashboard: true

entryPoints:
  http:
    address: ":80"
  https:
    address: ":443"

providers:
  docker:
    endpoint: "unix:///var/run/docker.sock"
    exposedByDefault: false

certificatesResolvers:
  http:
    acme:
      email: [email protected]
      storage: acme.json
      httpChallenge:
        entryPoint: http

3.4 Setup Traefik

Create traefik network

docker network create proxy

Generate traefik basic auth information (1)

sudo apt-get install apache2-utils
echo $(htpasswd -nbB yourUserName yourPassword) | sed -e s/\\$/\\$\\$/g

Create Traefik Docker Compose file: replace USER:PASSWORD with generated value above (1)

location: /opt/containers/traefik/docker-compose.yml

version: '3'

services:
  traefik:
    image: traefik:v2.0
    container_name: traefik
    restart: unless-stopped
    security_opt:
      - no-new-privileges:true
    networks:
      - proxy
    ports:
      - 80:80
      - 443:443
    volumes:
      - /etc/localtime:/etc/localtime:ro
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./data/traefik.yml:/traefik.yml:ro
      - ./data/acme.json:/acme.json
    labels:
      - 'traefik.enable=true'
      - 'traefik.http.routers.traefik.entrypoints=http'
      - 'traefik.http.routers.traefik.rule=Host(`traefikdomain.local`)'
      - 'traefik.http.middlewares.traefik-auth.basicauth.users=USER:PASSWORD'
      - 'traefik.http.middlewares.traefik-https-redirect.redirectscheme.scheme=https'
      - 'traefik.http.routers.traefik.middlewares=traefik-https-redirect'
      - 'traefik.http.routers.traefik-secure.entrypoints=https'
      - 'traefik.http.routers.traefik-secure.rule=Host(`traefikdomain.local`)'
      - 'traefik.http.routers.traefik-secure.middlewares=traefik-auth'
      - 'traefik.http.routers.traefik-secure.tls=true'
      - 'traefik.http.routers.traefik-secure.tls.certresolver=http'
      - 'traefik.http.routers.traefik-secure.service=api@internal'

networks:
  proxy:
    external: true

replace traefikdomain.local with your domain for traefik

Start traefik

cd /opt/containers/traefik
docker-compose up -d

browse traefikdomain.local to check the traefik manage page

4. Install portainer

Create portainer docker-compose file

location: /opt/containers/portainer/docker-compose.yml

version: '3'

services:
  portainer:
    image: portainer/portainer:latest
    container_name: portainer
    restart: unless-stopped
    security_opt:
      - no-new-privileges:true
    networks:
      - proxy
    volumes:
      - /etc/localtime:/etc/localtime:ro
      - /var/run/docker.sock:/var/run/docker.sock:ro
      - ./data:/data
    labels:
      - "traefik.enable=true"
      - "traefik.http.routers.portainer.entrypoints=http"
      - "traefik.http.routers.portainer.rule=Host(`portainerdomain.local`)"
      - "traefik.http.middlewares.portainer-https-redirect.redirectscheme.scheme=https"
      - "traefik.http.routers.portainer.middlewares=portainer-https-redirect"
      - "traefik.http.routers.portainer-secure.entrypoints=https"
      - "traefik.http.routers.portainer-secure.rule=Host(`portainerdomain.local`)"
      - "traefik.http.routers.portainer-secure.tls=true"
      - "traefik.http.routers.portainer-secure.tls.certresolver=http"
      - "traefik.http.routers.portainer-secure.service=portainer"
      - "traefik.http.services.portainer.loadbalancer.server.port=9000"
      - "traefik.docker.network=proxy"

networks:
  proxy:
    external: true

replace portainerdomain.local with your domain for portainer

Start portainer

cd /opt/containers/portainer
docker-compose up -d

browse portainerdomain.local for portainer web control panel
